Technical Data
- Valve size (DN) : 15 – 150
- Working pressure (bar) : 40 max (acc.DN)
- Températures (°C): -50 /+ 280
- Full bore
Leakage Rate : EN12266-1 – Rate A (no leakage)
Options
- Stem extension with ISO5211 top flange
- Manual stem extension
- Spring return handle
- Oval handle
Flange connection
- Flange PN40 (DN15-50)
- Flange PN16 (DN65-150)
Advantages:
- Face to Face : ISO5752-S01
- ISO5211 top flange
- High flow rate coefficient Kv
- Anti blowout system in standard
